FF10X series
Mark-Free Suction Cups
-
-
-
-
-
-
1. Suction Cup
Code Description FF10X-N Mark-free suction cup, 10 mm, Nitrile (NBR) FF10X-S Mark-free suction cup, 10 mm, Silicone FF10X-WS Mark-free suction cup, 10 mm, White silicone FF10X-WS(FDA) Mark-free suction cup, 10 mm, White silicone (FDA) FF10X-HS Mark-free suction cup, 10 mm, High temp silicone FF10X-CS Mark-free suction cup, 10 mm, Conductive silicone FF10X-U Mark-free suction cup, 10 mm, Urethane FF10X-A Mark-free suction cup, 10 mm, Mark free 2. Fitting Size
Code Description Blank No fitting M4M Fitting, M4 x P0.7 male 1. Recommended Lifting Maximum Force
Diameter Volume Lifting Force (↑), Kg (mm) (cm³) -20 kPa -60 kPa -90 kPa 10.4 2.30 0.12 0.30 0.40 2. Weight
Part Number Description Weight (g) FF10X-N Mark-free suction cup, 10 mm, Nitrile (NBR) 0.18 FF10X-S Mark-free suction cup, 10 mm, Silicone 0.17 FF10X-WS Mark-free suction cup, 10 mm, White silicone 0.17 FF10X-WS(FDA) Mark-free suction cup, 10 mm, White silicone (FDA) 0.17 FF10X-HS Mark-free suction cup, 10 mm, High temp silicone 0.18 FF10X-CS Mark-free suction cup, 10 mm, Conductive silicone 0.18 FF10X-U Mark-free suction cup, 10 mm, Urethane 0.18 FF10X-A Mark-free suction cup, 10 mm, Mark free 0.20 M4M Fitting, M4 male 1.25 3. Material Specifications
Material Hardness Shore (°) Color Temperature (℃) NBR 60 Black -20 ~ 110 Silicone 55 Red -70 ~ 200 White Silicone 55 Translucent White -70 ~ 200 White Silicone (FDA) 55 Translucent White -70 ~ 200 High Temp. Silicone 50 Blue -70 ~ 280 Conductive Material 70 Smoky Black -45 ~ 90 Urethane 60 Dark Green 0 ~ 100 Mark Free 75 Black -10 ~ 100 4. Material Resistance
Description Wear Resistance Oil Weather/Ozone Alcohol Acid NBR Excellent Excellent Fair Good Fair Silicone Good Poor Excellent Good Poor White Silicone Good Poor Excellent Good Poor High Temp. Silicone Good Poor Excellent Good Poor Conductive Silicone Good Poor Excellent Good Poor Urethane Excellent Excellent Excellent Fair Poor Mark Free Good Excellent Excellent Good Excellent
